Economical high speed printing slotting die cutting machine
To be configured according to user's needs.
Share to
- 产品描述
-
Specifications
Color group To be configured according to user's needs Printing paper A,B,C,A/B,B/C and A/B/C type corrugated paperboard(the maximum interval 11mm) Machine model 0920 1225 1425 Max.paper size 900x2200mm 1200x2600mm 1400x2600mm Max.printing size 900x2000mm 1200x2500mm 1400×2500mm Skip feeding paper 1100x2200mm 1400x2600mm 1600x2600mm Min.paper size 260x500mm 380x650mm 380x650mm Printing plate thickness 7.2mm 7.2mm 7.2mm Design speed(piece/min) 200pcs/min 180pcs/min 160pcs/min Economic speed(piece/min) 80-180pcs/min 80-16Opcs/min 80-140pcs/min Tinted precision (color)±0.5mm (color)±0.5mm (color)±0.5mm Slotting precision ±1.5mm ±1.5mm ±1.5mm Max.slotting depth 7×220mm 7x300mm 7x350mm increase the blade,increase the slot depth Min. Slot distance Positive knife
Negative knife150x150x150x150mm
250x90×250x90mm170x170x170x170mm
260x90x260x90mm170x170x170x170mm
260x90x260x90mmMax.die-cutting size 800x2100mm 1100×2500mm 1300×2500mm Printing plate diameter
(contain plate thickness)φ300mm φ410mm φ480mm
